SICK PBS plus User Manual

Operating Instructions PBS plus
OPERATING INSTRUCTIONS PBS plus8024946 | SICK AG
Subject to change without notice
55
6. FAULTS
Fault Possible cause Measure
No output signal Line break Check passage
No output signal No/Incorrect auxiliary energy Correct auxiliary energy
No/Incorrect output signal Wiring error or switchover of switching logic/analog signal
Observe pin assignment
Check output conguration
Observe pin assignment
Constant output signal during change
in pressure
Mechanical overload due to excessive pressure
Exchange device; consult with
the manufacture in the event
of repeated failure
Deviating zero point signal Overload pressure limit exceeded
Permissible overload pres-
sure limit upheld
Signal range too small Mechanical overload due to excessive pressure
Exchange device; consult with
the manufacture in the event
of repeated failure
Signal range too small Auxiliary voltage too high/low Correct auxiliary energy
Signal range falls Moisture has entered the device Mount cable correctly
Signal range falls/too small
Membrane damage, e.g. caused by abrasive/aggressive
media, corrosion to membrane/process connection
Contact manufacturer and
exchange device
Warnings and errors
Device-internal warnings and errors are output via the digital display. The device continues to
measure if there are pending warnings. The output signal and the switching outputs continue to be
output.
The following table shows the codes and their meaning.
Warning Description
ATT1
When the switching point was changed, the reset switching point was automatically
lowered by the smallest hysteresis of 0.25% by the device.
ATT2 Zero point offset, prevailing pressure outside the limits
ATT3 Password entry for menu access faulty
ATT4 Unit cannot be shown on the display, previous unit is used
