9. TECHNICAL DATA
G L1
G ¼ A DIN 3852-E 14 (0.55)
G L1 L2 L3 D1
G ¼
EN
837
20
(0.79)
13
(0.51)
10
(0.39)
ø 25
(0.98)
G L1 L2 L3 D1
G ½
B
1)
23
(0.91)
20.5
(0.81)
10
(0.39)
ø 18
(0.71)
G L 1
¼ NPT 13 (0.51)
Female thread Flush-mounted
1)
Weld-in connection recommended as dened counter
thread
