Operating Instructions PBS
Specications Model PBS
Pressure ranges bar 1 1.6 2.5 4 6 10 16 25
Overpressuresafety bar 2 3.2 5 8 12 20 32 50
Burst pressure
bar 5 10 10 17 34 34 100 100
Pressure ranges
bar 40 60 100 160 250 400 600
Overpressuresafety bar 80 120 200 320 500 800 1200
Burst pressure bar 400 550 800 1000 1200 1700 2400
MPa and kg/cm
2
areavailable
Absolutepressure:0...1barbis0...25bar
Vakuumdruck:-1…0barbis-1…24bar
Pressure ranges
psi 15 25 30 50 100 160 200 300
Overpressuresafety psi 30 60 60 100 200 290 400 600
Burst pressure
psi 75 150 150 250 500 500 1500 1500
Pressure ranges
psi 500 1000 1500 2000 3000 5000 8000
Overpressuresafety psi 1000 1740 2900 4000 6000 10000 17400
Burst pressure psi 2500 7975 11600 14500 17400 24650 34800
Absolutepressure:0...15psibis0...300psi
Fatigue life 10 Mio. max. load cycles
Materials
 Wetted parts
» Pressure connection 316 L
» Pressure sensor 316 L (up to 0 ... 10 bar rel 13-8 PH)
 Case
» Lower body 316 L
» Plastic head PC + ABS
» Keyboard TPE-E
» Display window PC
