HELP The HELP button toggles a help screen on the right side of the user inter‐
face for each configuration page. This provides more information about the
SIG200 as it relates to each page.
Please use for more detailed information always the operating manual. The
help texts does not include all information from the operating manual.
NOTE
The HELP screen will stay open while toggling different configuration pages
on the configuration tree.
Menu Clicking on this button the “Page selection” menu can be shown or hidden
to make navigation on smaller screens easier.
NOTE
The button is highlighted light blue when the device tree is hidden.
Home The home button will always navigate back to the Status device page.
Refresh page Clicking on this button the page contents are refreshed.
Device informa‐
tion
This area on the top left side of the page shows the product name, user-
defined location, firmware version, and serial number.
Page contents This area shows the selected page.
SETTINGS The settings page allows the user to change language and password.
Device notifica‐
tions
SIG200 device notifications will appear on the bottom of the screen. These
are informational only for configuration exchanges and errors. Each notifica‐
tion can be acknowledged by clicking on the entry.
