SICK TR4 Direct Rectangular - Dimensional Drawings; Sensor Dimensional Drawing

9.3 Dimensional drawings
9.3.1 Sensor dimensional drawing
24,99 20,65
9,96
13,41
88,14
57,96 62,53 77,98 82,55
4,57
10,67
18,54
4,57
4,57
M12 × 1
9,7
Ø 5,08
Figure 11: Sensor dimensional drawing (mm) (version with male connector)
9 T
ECHNICAL DATA
26
O P E R A T I N G I N S T R U C T I O N S | TR4 Direct Rectangular 8023286/15V1/2019-11-22 | SICK
Subject to change without notice
