10 Ordering information
10.1 TR4 Direct standard ordering information
Scope of delivery: Sensor, actuator, operating instructions
T
able 10: Safety switch part numbers
Coding Sensor connection type Type code Part number
Universally coded Cable 3 m, PVC TR4-SDM03PB 6070803
Cable 10 m, PVC TR4-SDM10PB 6070804
Cable with male connector,
M12, 8-pin
TR4-SDM01CB 6070805
Cable with male connector,
M12, 5-pin
TR4-SDM02CB 6070821
Uniquely coded Cable 3 m, PVC TR4-SDU03PB 6070806
Cable 10 m, PVC TR4-SDU10PB 6070807
Cable with male connector,
M12, 8-pin
TR4-SDU01CB 6070808
Cable with male connector,
M12, 5-pin
TR4-SDU02CB 6070822
10.2 TR4 Direct with boundary area indication ordering information
Scope of delivery: Sensor, actuator, operating instructions
T
able 11: Safety switch part numbers
Coding Sensor connec‐
t
ion type
Type code Part number
Universally coded Cable 3 m, PVC TR4-SEM03PB 6070809
Cable 10 m, PVC TR4-SEM10PB 6070810
Cable with male
connec
tor, M12,
8-pin
TR4-SEM01CB 6070811
Cable with male
connector, M12,
5-pin
TR4-SEM02CB 6070823
Uniquely coded Cable 3 m, PVC TR4-SEU03PB 6070812
Cable 10 m, PVC TR4-SEU10PB 6070813
Cable with male
connec
tor, M12,
8-pin
TR4-SEU01CB 6070814
Cable with male
connec
tor, M12,
5-pin
TR4-SEU02CB 6070824
10.3 TR4 Direct ordering information with boundary area indication and magnetic hold‐
in
g force
Scope of delivery: Sensor, actuator, operating instructions
10 OR
DERING INFORMATION
