SICK TR4 Direct Rectangular - Actuator Dimensional Drawing

9.3.2 Actuator dimensional drawing
24,99
88,14 68,31 72,9 77,98
20,65 18,54
10,66
7,11
6,78
4,57
4,57
Ø 5,08
Figure 12: Actuator dimensional drawing (mm)
TECHNICAL DATA 9
