Siebeck GmbH Translation of the original operating manual jet_in_bed_0315
Seite 10
Inserting the string
D - 69412 EBERBACH
Elektischer Anschlußwert Electrical supply
KW
Volt Hz
Machinetype
Maschinentyp
Maschinen-Nr.
Machine-N°
Baujahr
Year of constr.
Maschinenbez.
Masch.gewicht
Machineweight
Machinename
Verschnürungsmaschine / Tyingmachine
Ph.AC
Internet: www.siebeck.de email: info@siebeck.de
1
0
BCD A E 21
3
4
5
F
G
1. Insert bobbin holder (A) with string bobbin (B) into the pick-up (C)
and tighten with wing nut (D).
2. Thread string through between the brake plates (E)
3. Thread into the five string rollers reels starting at 1, and in the
sequence up to 5, and then through the hole (F) in the needle shoe
from top to bottom thread
4. Pull end of string (G) with your right hand as far as the right, rear
table top corner and hold there
5. Start the machine via the foot pedal. The string is then automatically
inserted underneath the table top and cut off
Attention Risk of crushing!
Make sure you keep the opening in the middle of the table top
clear.
When inserting the needle here, there is a considerable risk of
injury.
