Siebeck GmbH Translation of the original operating manual jet_in_bed_0315
Seite 7
Technical data
Machinery dimensions
D - 69412 EBERBACH
Elektischer Anschluß wert Electrical supply
KW
Volt Hz
Machinetype
Maschinentyp
Maschinen-Nr.
Machine-N°
Baujahr
Year of constr.
Maschinenbez.
Masch.gewicht
Machineweight
Machinename
Verschnürungsmaschine / Tyingmachine
Ph.AC
Internet: www.siebeck.de email: info@siebeck.de
SEW
1
0
122,5 - 222,5
450,0
275,0
1575,0 - 1675,0
310,0
2450,0 - 2550,0
250,0
560,0
850,0 - 950,0
410,0
690,0
200,0
105,0
120,0
All dims. in mm, changes reserved
Electrical connection values: 400 Volt, 3 phase power supply, 1 kW, 50 Hz
Machine performance: up to 40 cycles p. min. (based on product size)
Machine weight: 130 kg
Noise pressure level: < 79 dB(A) as per EN 11204
(without product / without string)
Proper use:
Solely commercial / strapping of preferably ring-shaped products
RING DIMENSIONS
A
B
C
Ringabmessungen
maximal minimal
A
B
C
600 mm 80 mm
500 mm 70 mm
400 mm 5 mm
