Siebeck GmbH Translation of the original operating manual jet_in_bed_0315
Seite 14
Adjusting the zero position on the aggregate
JAG-07-050
-S3
-S2
"O"
-S10
-M2
The correct zero point (“O“) is achieved if the inserting lever JAG-07-
050 has reached its furthest left position.
The zero point is adjusted by sliding the end switch -S3.
Only authorised and trained staff are allowed to perform this
setting!!
