6 3ZX1012-0RB22-1CA1
2.9 Additional safety instructions
2.10 Ambient conditions
Permissible ambient temperature range
• Storage / transport: -40 °C to +80 °C
• Operation: -25 °C to +60 °C
This device is maintenance-free.
The warranty implies the observance of these safety and commission-
ing instructions as well as the operating instructions (order No.
3ZX1012-0RB22-1AA1 (3RB22), 3ZX1012-0RB24-1AA1 (3RB24) and
order No. 3ZX1012-0RB00-1AA1 (3RB29).
Further information on the 3RB22 / 3RB24 / 3RB29 device can be
found in the Siemens IC 10 catalog or on the Internet:
http://support.automation.siemens.com/
CAUTION
3RB22 / 3RB24 and 3RB29 are not designed for use in hazardous
areas. When used in potentially explosive areas, 3RB22 / 3RB24
and 3RB29 devices must be adapted according to the respective
ignition protection type.
The 3RB22 / 3RB24 is not designed for load-side operation at
frequency converters.
NOTICE
Brief power failures (voltage drops) < 150 ms at the 3RB22 do not
lead to a protective system failure.
Long power failures (voltage drops) >150ms at the 3RB22 cause
the output relays to be deactivated.
NOTICE
Brief power failures (voltage drops) <89ms at the 3RB24 do not
lead to a protective system failure.
Long power failures (voltage drops) >89ms at the 3RB24 cause
the output relays to be deactivated.
3. Safety data 3RB22 / 3RB24
Values in the safety and
commissioning notes for 40°C
ambient temperature plus 10K
due to self-heating
SIL SIL 1
HFT 0
lsafe 1404,08 Fit
l
DD 649,95 Fit
l
DU 256,02 Fit
SFF 88,59%
DC 71,7%
MTBF: 47 Jahre
PFD
avg (36 Months)
5,54 10
-3
Architektur 1oo1
T1-Value
(periodic inspection) 36 Months
T
Iifetime
20 Years
4. Maintenance and repair
5. Warranty
6. Further information
