Communication System Manual 3WN1, 3WS1 Circuit-Breakers
86  Copyright Siemens AG 1998. All rights reserved. Version 1.0 (08/98)
Step 7: Bus configuration
If SIMATIC S5 is the bus master, the bus can be configured quickly and easily using either a PC or a
SIMATIC programming device (PG) in conjunction with the COM ET 200 or COM-PROFIBUS programs
60
.
In the case of other bus masters, the appropriate devices and/or supplier-specific tools must be used.
The object of bus configuration is to define the 3WN1/3WS1 device data, the 3WN1/3WS1 bus address and
the 3WN1/3WS1 data area (I/O area) in the bus master. The 3WN1/3WS1 device data can be read into the
master in the form of type or GSD files.
Bus data areas
Table 11: Data area of 3RK1002 interface module
I/O
Octet Bit no. Description
area
7 6 5 4 3 2 1 0
0 1 0 0 Maximum phase current in phase L1 1 input
byte
0 1 Maximum phase current in phase L2
1 0 Maximum phase current in phase L3
1 2 0 0 0 0 Rated circuit-breaker current
Test
1 input
byte
0 0 0 1 Rated circuit-breaker current 315 A
0 0 1 0 Rated circuit-breaker current 400 A
0 0 1 1 Rated circuit-breaker current 500 A
0 1 0 0 Rated circuit-breaker current 630 A
0 1 0 1 Rated circuit-breaker current 800 A
0 1 1 0 Rated circuit-breaker current 1000 A
0 1 1 1 Rated circuit-breaker current 1250 A
1 0 0 0 Rated circuit-breaker current 1600 A
1 0 0 1 Rated circuit-breaker current 2000 A
1 0 1 0 Rated circuit-breaker current 2500 A
1 0 1 1 Rated circuit-breaker current 3150 A
1 1 0 0 Rated circuit-breaker current 4000 A
1 1 0 1 Rated circuit-breaker current 5000 A
1 1 1 0 Rated circuit-breaker current 6000 A
1 1 1 1 Rated circuit-breaker current 6300 A
0 0 Actually displayed phase L1
0 1 Actually displayed phase L2
1 0 Actually displayed phase L3
1 1 Actually displayed phase Lmax
60)
cf. "ET 200 Distributed I/Os" manual, order number 6ES5 998-3ES12.
