Communication System Manual 3WN1, 3WS1 Circuit-Breakers
Version 1.0 (02/98) Copyright Siemens AG 1998. All rights reserved. 87
2 3 0 0 0 0 0 0 0 1 Button pressed on
display
1 input byte
0 0 0 0 0 0 1 0 "a" release
0 0 0 0 0 1 0 0 "n/z" release
0 0 0 0 1 0 0 0 "g" release
0 0 0 1 0 0 0 0 Phase imbalance
0 0 1 0 0 0 0 0 Watchdog
(microprocessor fault)
0 1 0 0 0 0 0 0 Overload
1 0 0 0 0 0 0 0 Temperature alarm
3 4 Phase 1 current 1 input word
5
5 6 Phase 2 current 1 input word
7
7 8 Phase 3 current 1 input word
9
