131
LOGO! Manual
A5E00067781 01
Each parameter is identified by the block number and the
parameter abbreviation. Examples:
B01:T
Block number Parameter abbreviation
T: ...is a time that can be set.
No1: ...is the first cam of a time switch (clock).
Par: ...refers to several counters that can be monitored.
5.1.2 Selecting a Parameter
To select a parameter, proceed as follows:
1. Select the ’Set Param’ option from the parameterization
menu.
Set Clock
>Set Param
2. Press the OK key
LOGO! displays the first parameter. If parameters can-
not be set, you can use ESC to return to the parameter-
ization menu.
Parameterizin
LOGO!
