Siemens 6ED1 052-1CC00-0BA2 User Manual

LOGO! Manual
A5E00067781 01
192
LOGO! 230RCL
LOGO! 230RCLB11
LOGO! 230RC
LOGO! 230RCo
Derating None throughout
the entire tempera-
ture range
None throughout
the entire tempera-
ture range
Parallel switching of outputs
to increase power
Not permitted Not permitted
Protection of output relay (if
desired)
Max. 16 A,
characteristic B16
Max. 16 A,
characteristic B16
Switching rate
Mechanical 10 Hz 10 Hz
Ohmic load/lamp load 2 Hz 2 Hz
Inductive load 0.5 Hz 0.5 Hz
ASi–slave connection (LOGO! 230RCLB11 only)
ASi profile
 I/O config
 ID code
7.F
7
h
F
h
Number of virtual digital in-
puts
4
Number of virtual digital out-
puts
4
Power supply ASi power supply
unit
Power consumption Typically 30 mA
Electrical isolation Yes
Reverse polarity protection Yes
Technical Specifications

Siemens 6ED1 052-1CC00-0BA2 Specifications

General

Model Number	6ED1 052-1CC00-0BA2
Digital inputs	8
Digital outputs	4
Protection class IP	IP20
Connection Type	Screw-type terminals
Dimensions	72 x 90 x 55 mm
Product Type	LOGO!
Relay outputs	4
Memory	Not applicable
Operating temperature	-20 °C to +55 °C
Number of Inputs	8
Compatibility	LOGO! Series
