LOGO! Manual
A5E00067781 01
198
LOGO! 24RCL
LOGO! 24RCLB11
LOGO! 24L
Short–circuit proof cos 0.5 to
0.7
Power protection
B16
900A
Parallel switching of outputs
to increase power
Not permitted Not permitted
Protection of output relay (if
desired)
Max. 16 A,
characteristic B16
Switching rate
Mechanical 10 Hz
Electrical 10 Hz
Ohmic load/lamp load 10 Hz 2 Hz
Inductive load 0.5 Hz 0.5 Hz
ASi slave connection(LOGO! 24RLCB11 only)
ASi profile
I/O config
ID code
7.F
7
h
F
h
Number of virtual digital in-
puts
4
Number of virtual digital out-
puts
4
Power supply ASi power supply
unit
Power consumption Typically 30 mA
Electrical isolation Yes
Reverse polarity protection Yes
Technical Specifications
