The example program consists of the following:
Block Function
Memory area
no.
Par RAM Timer REM Blocks
B01 OR 0 0 0 0 1
B02 AND 0 0 0 0 1
B03 Time switch 6 2 0 0 1
B04 On delay 1 1 1 0 1
B05 Clock pulse generator 1 1 1 0 1
B06 AND 0 0 0 0 1
Resources occupied by the
program
8 4 2 0 6
Memory limitations in LOGO! 48 27 16 15 56
Still available in LOGO! 40 23 14 15 50
The program therefore fits into LOGO!.
