LOGO! Manual
A5E00067781 01
32
The overview display shows you three displays of LOGO!,
which together make up the program. As you can see
LOGO! links the blocks with one another by means of the
block numbers.
Advantages of the block numbers
You can connect almost any block to an input of the current
block using its block number. In this way you can use the
interim results of logic or other operations more than once.
This saves you the work required to enter things again as
well as memory space, and ensures that your circuit re-
mains clear. In this case you have to know how LOGO! has
named the blocks.
Note
To make working with LOGO! particularly efficient, we rec-
ommend that you draw up a diagram overview of the pro-
gram. This will make it easier to create the program. You
can then enter the block numbers assigned by LOGO! in
this diagram.
If you use the LOGO!Soft software to program LOGO!,
you can display and print out a ladder program. You can
create a functional block diagram of your program straight
away using LOGO!Soft Comfort.
