7-9
Primer: S7-300 Programmable Controller, Quick Start
C79000-G7076-C500-01
The program status is only displayed for the area visible to the editor.
Network 1:
Network 2 : Green phase for vehicles
I 0.0
I 0.1
M 0.0
M 0.0 Q 0.7
T 6 T 5
M 0.0
Detecting green request for pedestrians
Figure 7-4 Example of Displaying the Program Status in LAD
And that’s it. That’s how quickly you get
successful results as promised with our
S7-300:
an executable user program in LAD!
Displaying the
Program Status in
LAD
Downloading and Testing Your User Program
