Diagnostics
3.2 Error types
2AI TC ST analog electronic module (6ES7134-4JB00-0AB0)
16 Manual, 04/2007, A5E01076883-01
3.2 Error types
Analog input module error types
Table 3-1 Error types
Error type Meaning Remedy
16
D
10000:
Parameter
assignment
error
Module cannot use the
parameter for the channel:
Inserted module does not
match the one configured.
Incorrect parameter
assignment.
Correct the configuration (align
actual and set configuration).
Correct the parameter
assignment (wire break
diagnostics only parameterized
for the permitted measuring
ranges).
9
D
01001: Error Internal module error
(diagnostic message at
channel 0 applies to the entire
module)
Replace the module.
7
D
00111: Upper
limit exceeded
Value is above the overrange. Correct the module/final
controlling element tuning.
8
D
01000: Lower
limit value
undershot
Value is below the underrange. Correct the module/final
controlling element tuning.
6
D
00110:
Open circuit
Line to the encoder
interrupted.
Correct the process wiring.
21
D
10101:
Reference
channel error
*
Error on the reference channel Check the reference module (2
AI RTD ST).
Reference channel error is not reported if the RTD module is not parameterized in the GSD file using
the PT100 Climatic. This applies to IM151-1 HIGH FEATURE (6ES7151-1BA00-0AB0 or higher),
IM151-7 CPU and IM151-3 PROFINET IO (6ES7151-3AA00-0AB0 or higher).
