Connecting
5.2 Connecting thermocouples
2AI TC ST analog electronic module (6ES7134-4JB00-0AB0)
32 Manual, 04/2007, A5E01076883-01
Relevant parameters to be set for the interface module:
Parameters Value
Reference junction slot 3
Reference junction input RTD at Channel 0
Relevant parameters to be set for the 2AI TC:
Slot Parameters Value
Reference junction E0 RTD
Reference junction E1 None
Reference junction number 1
Type/range of measurement E0 TC-EL Type...
5 (2AI TC)
Type/range of measurement E1 (any)
Reference junction E0 RTD
Reference junction E1 RTD
Reference junction number 1
Type/range of measurement E0 TC-EL Type...
8 (2AI TC)
Type/range of measurement E1 TC-EL Type...
Reference junction E0 None
Reference junction E1 RTD
Reference junction number 1
Type/range of measurement E0 (any)
11 (2AI TC)
Type/range of measurement E1 TC-EL Type...
Non-isolated thermocouples
When you use non-isolated thermocouples, you must comply with the permitted common-
mode voltage.
