Properties
1.1 2AI TC ST analog electronic module (6ES7134-4JB00-0AB0)
2AI TC ST analog electronic module (6ES7134-4JB00-0AB0)
Manual, 04/2007, A5E01076883-01
9
2AI TC ST technical data (6ES7134-4JB00-0AB0)
Dimensions and weight
Width (mm) 15
Weight Approx. 40 g
Module-specific data
Supports isochronous operation No
Number of inputs 2
Cable length
Shielded
Max. 50 m
Parameter length 4 bytes
Address space 4 bytes
Voltages, currents, potentials
Rated load voltage L+ (from the power module) 24 VDC
Reverse polarity protection
Yes
Electrical isolation
Between the channels and backplane bus
Yes
Between the channels and load voltage L+
Yes
Between the channels
No
Between the channels and 24 V supply
voltage
Yes
Permissible potential difference
Between M
ANA
and the central grounding point
(U
iso
)
75 VDC / 60 VAC
Between the inputs and M
ANA
(U
CM
)
2 VAC
SS
Insulation tested 500 VDC
Current consumption
From load voltage L+
Max. 30 mA
Power dissipation of the module Typically 0.6 W
Status, interrupts, diagnostics
Diagnostics function
Group error
Red "SF" LED
Diagnostic functions readable
Yes
Analog value generation
Measuring principle Integrative
Integration time/conversion time/resolution per
channel:
Integration time can be assigned parameters
Yes
Interference frequency suppression in Hz
60 50
Integration time in ms
16,7 20
Basic conversion time incl. integration time in
ms
55 65
Additional conversion time for wire break
check diagnostics in ms
20 20
Cycle time in ms
Number of active channels per module x
conversion time
Resolution (including overrange)
15 bits plus sign
