Siemens 6SE7032-2EE85-1AA0 User Manual

05.00 Transport, Unpacking and Assembly
Siemens AG 6SE7087-6AK85-1AA0
2-7
Rectifier/Regenerating Unit Operating Instructions
43
Front cover
Printed-circuit board
Figure 2.6 Clearance between PCBs and front cover (size C)
27
44
PMU
82
Front of
enclosure
Printed-circuit board
Figure 2.7 Clearance between PCBs and PMU (size E)
Line connection without autotransfomer (size E)
(For sizes C, H and K, these connections have to be made externally on the system side.
Order No. for three
busbars
Unit Order No.
6SE7032-7FE87-3AE0
6SE7031-7EE85-1AA0
6SE7032-2EE85-1AA0
6SE7033-1EE85-1AA0
6SE7031-5FE85-1AA0
6SE7032-4FE85-1AA0
6SE7032-7FE85-1AA0
6SE7032-7HE87-3AE0
6SE7033-8EE85-1AA0
6SE7034-6EE85-1AA0
6SE7033-5FE85-1AA0
6SE7034-2FE85-1AA0
6SE7031-4HE85-1AA0
6SE7032-2HE85-1AA0
6SE7032-7HE85-1AA0
6SE7034-2HE87-3AE0
6SE7036-1EE85-1AA0
6SE7035-4FE85-1AA0
6SE7034-2HE85-1AA0
Regen. connection
Rect. connection
Busbar
Figure 2.8 Line connection w/o autotransformer (size E)
