09.02 Technical Data
Siemens AG 6SE7087 6AK85-1AA0
14-9
Rectifier/Regenerating Unit Operating Instructions
R/R unit 6SE70..-.....-1AA0 37-7HH85 41-0HH85 41-3HK85 41-5HK85 41-8HK85
Rated voltage, rated frequency, rated current
Rated voltage
Rectifier connection
Regenerative connection
DC link voltage
V
3AC 660V to 690V ±15%
using an (auto) transformer
1.2 times the voltage of the rectifier connection
DC 890V to 930V ±15%
Rated frequency f
n
Input
Output
Hz
46 to 64 (automatic frequency matching)
DC
Rated current
(rms value)
With autotransformer
Regenerating, line
side
Regenerating, unit
side
Rectifier operation
Without autotransformer
Regenerating, unit
side
Rectifier operation
A
741
617
671
617
671
980
817
888
817
888
1235
1029
1119
1029
1119
1401
1168
1269
1168
1269
1803
1502
1633
1502
1633
Load class I to EN 60146-1-1 of the DC link current (average value)
in rectifier operation; currents reduced to 92% in regenerative operation
Rated current
(average)
DC link connection
Rectifier operation
A 774 1023 1285 1464 1880
Load class II to EN 60146-1-1 of the DC link current (average value)
in rectifier operation; currents reduced to 92% in regenerative operation
Rated current A 704 931 1169 1332 1711
Base load duration s 240
Excess current A 1057 1396 1754 1998 2566
Excess current duration s 60
Losses, cooling
Power dissipation
−
Maximum
kW 3.70 4.15 5.54 5.97 7.62
Cooling air requirement m
3
/s 0.55 0.55 1.0 1.0 1.0
Sound pressure level, dimensions, weight
Sound pressure level 50 Hz
60 Hz
dB(A) 80
83
80
83
82
82
82
82
82
82
Size
Width
Height
Depth
mm
mm
mm
H
508
1400
551
H
508
1400
551
K
800
1725
550
K
800
1725
550
K
800
1725
550
Weight app. kg 175 175 450 450 470
Parallel units (-1AD0) of size K for connecting in parallel have the same technical data as the corresponding
"basic units" (-1AA0). Please note the unit correspondence and notes of Section 3.7!
The permissible output current in parallel mode is reduced (due to current division between the power sections)
by 10 % as compared to the sum of the rated currents of the separate power sections.
