16 Mechanical installation and wiring
ARCADIS Varic/Orbic SPR2-310.812.03.01.02 Siemens AG
09.06 CS PS SP
Page 16 of 20
Medical Solutions
Updating the footswitch symbols 2.2
• The accessory kit contains several symbols for the new footswitch. Affix them to the
footswitch as follows:
- Affix "Save Image" symbol (Fig. 11 / p. 16) here: (1/Fig. 15 / p. 18).
- Affix "Select Mode" symbol (Fig. 12 / p. 17) here:(2/Fig. 15 / p. 18).
- Affix "Release Radiation Pedal" symbol (Fig. 14 / p. 18) here:(3/Fig. 15 / p. 18).
- Affix "Fluoro Pedal" symbol (Fig. 13 / p. 17) here:(4/Fig. 15 / p. 18).
NOTE
For the ARCADIS Varic and ARCADIS Orbic, the functions of the
two footswitch pedals (up to software version VB13C) cannot be
changed. From software version VB13C onward, the foot pedal
functions will be alterable via the software.
The following description applies to the configuration with soft-
ware version VB13C and to the as-delivered state (default pro-
gramming) with software version VB13C or higher.
With software versions VB13C and higher, if the foot pedal func-
tions are swapped via reprogramming, the symbols to be affixed
must correspond to the functions that have been reprogrammed.
(Affix "Fluoro Pedal" symbol (Fig. 13 / p. 17) here:
(3/Fig. 15 / p. 18); affix "Release Radiation Pedal" symbol
(Fig. 14 / p. 18) here: (4/Fig. 15 / p. 18))
Fig. 11: "Save Image" symbol
