Administration
A31003-S2000-M102-3-76A9, 08/07/2009
3-78 Asterisk - OpenStage Family, Administration Manual
administration.fm
Programmable Keys
3.6.23 Mute (OpenStage 15 Only)
On pressing this key, the microphone is turned off. This programmable key function is available
only for OpenStage 15 phones, which have no fixed mute key.
3.6.24 Release (OpenStage 15 Only)
On pressing this key, the current call is disconnected. This programmable key function is avail-
able only for OpenStage 15 phones, which have no fixed release key.
3.6.25 Key Modules
A Key Module provides 12 additional program keys. Key Modules are available for OpenStage
15/40/60/80 phones. A maximum of 2 key modules can be connected to one phone.
The following table shows which key modules can be connected to the particular phone types.
The configuration of a key on the key module is just the same as the configuration of a phone
key.
Administration via WBM
System > Features > Key module 1/2
Phone Type OpenStag Key Module 15 OpenStage Key Module
OpenStage 15 1 -
OpenStage 40 1 2
OpenStage 60/80 - 2
>
Please note that OpenStage Key Modules (self-labeling) and
OpenStage
Key Module 15 (paper label) can not be combined. For Key Labelling, a
special tool is available; please refer to:
http://wiki.siemens-enterprise.com/index.php/Key_Labelling_Tool
