Siemens Climatix HMI-DM User Manual

6/36
Siemens Climatix HMI-DM CB1P3916en02
Building technologies Introduction 2015-07-02
1.5 Key features
- 8-line display with configurable blue and white backlight
- Easy-to-operate keys and knobs
- Programmable menu with easy-to-understand structure
- Key ALARM and INFO with LED indicators
- Definable user password for every access level
- Support of multi-language and Unicode fonts
- Support of online trend and time scheduler function
- Panel or wall mounting
- Powered by controller via process bus or local HMI connection
- Firmware upgrades over SCOPE tool or SD card
1.6 Reference documents
The following documents contain further information on the products described in
this document.
Document
Document No.
1
Data sheet “Climatix HMI-DM”
CB1Q3941en
2
Mounting instructions “Climatix HMI-DM”
CB1M3940en
3 Climatix controllers POL6xx and I/O modules POL9xx –
Basic documentation
CB1P3903en
4
CE declaration of conformity (POL895)
CB1T3941xx
5
Environment product declaration
CB1E3940_01
1.7 Product variant
HMI-DM variant
Cable
Version POL895.50/XXX for remote and
multiple controller installation. HMI-DM
is connected over Process bus (KNX-
based) network
2-wires cable only (not included)
Version POL895.51/XXX for local
service installation. HMI-DM is
connected over user interface port
Standard 8-wire twisted pair cable with
two RJ45 plugs (included HMI box)
