Siemens Codoor CD3500 - Codoor Installation Kit

8 CD3500 & CD4000 Installation and User manual
ENG
Codoor Installation kit
Make sure you have the following tools handy:
Cross-head screwdriver for door handle and cylinder ring screws.
Hack saw for trimming lever handle spindle.
The following parts are supplied:
1 Codoor (batteries excluded).
4 extension sleeves for handle nipples (use only one pair, M4 or
M5).
1 Reinforcing spring.
1 Reinforcing spring holder.
•
•
•
•
•
•
CD4000CD4000
CD3500CD3500
