Diagnostics
5.2 Error messages of the CP 243-1
CP 243-1
116 Operating Instructions, 03/2012, C79000-G8976-C244-02
Error word Description Reaction/remedy Transfer mechanism
Hex dec Byte offset in the
SM area
Return value
(ETHx_)
16#00B7 183 The administrator password is
too short.
Create configuration
with STEP 7 Micro/WIN
32
20, 21 _CTRL
16#00BB 187 Bad IDB format Create configuration
with STEP 7 Micro/WIN
32
20, 21 _CTRL
16#00BD 189 Initialization of the file system
failed
Delete files from the file
system
20, 21 _CTRL
16#00BF 191 System files could not be set
up in the file system
Delete files from the file
system
20, 21 _CTRL
16#00F0 240 The S7-200 CPU failed to
recognize the CP 243-1
Check configuration
and structure of the S7-
200 system
_CTRL
16#00F1 241 The address of the output
byte via which the CP 243-1
is supposed to be accessible
according to the configuration
is not compatible with the
current position of the CP
243-1 in the S7-200 system.
Check configuration
and structure of the S7-
200 system
_CTRL
16#0100
bis
16#0108
256
bis
264
Timeout on the S7 bus Automatic restart 20, 21 _CTRL
16#8080 32896 CP 243-1 not yet completely
started up.
If necessary, check 24
V supply
20, 21 _CTRL
Error messages in word format
