Configuration
3.4 Other options when configuring a CP 243-1
CP 243-1
70 Operating Instructions, 03/2012, C79000-G8976-C244-02
Byte offset in
variable memory
Description Data format Example
61-62 Local TSAP 2 bytes, hex 16#1300
63-64 Remote TSAP 2 bytes, hex See S7 connection 0 section.
S7 connection 4 section (If some bytes of this section are unused, pad them with16#00)
65 Flag byte
See S7 connection 0 section.
1 byte, hex See S7 connection 0 section.
66-69 IP address of the partner
See S7 connection 0 section.
4 bytes, hex See S7 connection 0 section.
70-71 Local TSAP 2 bytes, hex 16#1400
72-73 Remote TSAP 2 bytes, hex See S7 connection 0 section.
S7 connection 5 section (If some bytes of this section are unused, pad them with16#00)
74 Flag byte
See S7 connection 0 section.
1 byte, hex See S7 connection 0 section.
75-78 IP address of the partner
See S7 connection 0 section.
4 bytes, hex See S7 connection 0 section.
79-80 Local TSAP 2 bytes, hex 16#1500
81-82 Remote TSAP 2 bytes, hex See S7 connection 0 section.
S7 connection 6 section (If some bytes of this section are unused, pad them with16#00)
83 Flag byte
See S7 connection 0 section.
1 byte, hex See S7 connection 0 section.
84-87 IP address of the partner
See S7 connection 0 section.
4 bytes, hex See S7 connection 0 section.
88-89 Local TSAP 2 bytes, hex 16#1600
90-91 Remote TSAP 2 bytes, hex See S7 connection 0 section.
S7 connection 7 section (If some bytes of this section are unused, pad them with16#00)
92 Flag byte
See S7 connection 0 section.
1 byte, hex See S7 connection 0 section.
93-96 IP address of the partner
See S7 connection 0 section.
4 bytes, hex See S7 connection 0 section.
97-98 Local TSAP 2 bytes, hex 16#1700
99-100 Remote TSAP 2 bytes, hex See S7 connection 0 section.
