Configuration
3.4 Other options when configuring a CP 243-1
CP 243-1
Operating Instructions, 03/2012, C79000-G8976-C244-02
71
Byte offset in
variable memory
Description Data format Example
STEP 7 Micro/Win server section
101 Flag byte
• Bit [0] server
– 0: server
– 1: not supported
• Bit [1] keepalive
– 0: no keepalive support
– 1: keepalive support
• Bit [2-6] not used
• Bit [7] section valid
– 0: not supported
– 1: section used
1 byte, hex
16#82:
server, keepalive support,
STEP 7 Micro/WIN server
section is used and contains
valid data.
102-105 Internal system use 4 bytes, hex
CRC section
106-107 CRC covering all CDB bytes without
the CRC section itself
2 bytes, hex
