Siemens CU240E-2 - Standard Drive Control

Commissioning
4.2 Commissioning with BOP-2 operator panel
CU240B-2 and CU240E-2 Control Units
22 Compact Operating Instructions, 01/2017, A5E39910322B AA
Application class
Standard Drive Control
Dynamic Drive Control
Power Modules
that can be op-
erated
PM240-2, PM240P-2
Max. output
frequency
550 Hz 240 Hz
Torque control
Without torque control
Speed control with lower-level torque control
Commissioning
• Contrary to "Dynamic Drive Control" a speed
controller does not have to be set
• In comparison to the "EXPERT" setting:
– Simplified commissioning using preas-
signed motor data
– Reduced number of parameters
• Standard Drive Control is preset for Power
Modules, frame size A … frame size C
• Reduced parameter quantity when compared
to the "EXPERT" setting:
• Dynamic Drive Control is preset for Power
Modules, frame size D … frame size F
4.2.2
Standard Drive Control
Select the motor standard.
● KW 50HZ: IEC
● HP 60HZ: NEMA
● KW 60HZ: IEC 60 Hz
Set the inverter supply voltage.
Select the motor type. If a 5-digit motor code is stamped on the motor rating plate, select the
corresponding motor type with motor code.
Motors without motor code stamped on the rating plate:
● INDUCT: Third-party induction motor
● 1L… IND: 1LE1, 1LG6, 1LA7, 1LA9 induction motors
Motors with motor code stamped on the rating plate:
● 1LE1 IND 100: 1LE1 . 9
● 1PC1 IND: 1PC1
● 1PH8 IND: Induction motor
● 1FP1: Reluctance motor
Depending on the inverter, the motor list in BOP-2 can deviate from the list shown above.
If you have selected a motor type with motor code, you must now enter the motor code. The
inverter assigns the following motor data corresponding to the motor code.
If you do not know the motor code, then you must set the motor code = 0, and enter motor
data from p0304 and higher from the rating plate.
