Siemens Delta Series User Manual

GAMMA instabus
Technical Product Information
March 2008
DELTA profil Display and control unit UP 585 5WG1 585-2AB_1
DELTA style Display and control unit UP 584 5WG1 584-2AB_1
DELTA ambiente Display and control unit UP 586 5WG1 586-2AB_1
Technical Manual UP 58x, 6 pages Siemens AG
Automation and Drives Group
Update: http://www.siemens.com/gamma © Siemens AG 2008 Electrical Installation Technology
Subject to change without prior notice P.O. Box 10 09 53, D-93009 Regensburg
2.3.1.2/6
Dimension Driver
Dimensions in mm
Dimension Display unit
Dimensions in mm
General Notes
• The operating instructions must be handed over to the
client.
• Any faulty device should be returned to the local
Siemens office.
• If you have further questions concerning the product
please contact our technical support:
! +49 (180) 5050-222
! +49 (180) 5050-223
" www.siemens.com/automation/support-request
71
71
16
65
33
65
20
