Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
132 Manual, 07/2018, A5E42674880-AA
Technical specifications
15
15.1
Technical specifications
Technical specifications of the AI Energy Meter HF
The following table shows the technical specifications as of 07/2018. You will find a data
sheet including daily updated technical specifications on the Internet
(https://support.industry.siemens.com/cs/ww/en/pv/6ES7134-6PA00-0CU0/td?dl=en
).
Article number
6ES7134-6PA00-0CU0
General information
Product type designation AI Energy Meter 480 VAC/CT HF, PU 1
Firmware version V6.0
• FW update possible
Yes
usable BaseUnits BU type U0
Color code for module-specific color identifica-
tion plate
CC20
Supported power supply systems
TT, TN, IT
Product function
• Voltage measurement
Yes
– without voltage transformer
Yes
– with voltage transformer
Yes
• Current measurement
Yes
– without current transformer
No
– with current transformer
Yes; 1 A or 5 A current transformer
– with Rogowski coil
No
– with current/voltage transformer
No
• Energy measurement
Yes
• Frequency measurement
Yes
• Power measurement
Yes
• Active power measurement
Yes
• Reactive power measurement
Yes
• Power factor measurement
Yes
• Active factor measurement
Yes
• Reactive power compensation
Yes
• Line analysis
Yes
