Measured value data records
E.10 Measured value data record for phase-based measured values L3 (DS 149)
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
255
E.10.2
Measured value data record for phase-based measured values L3 (DS 149)
version 1
Measured variables of the module
The measured value identification (measured value ID) is an index which references the
overview table of the measured variables in appendix B (Measured variables (Page 163)).
Byte
Measured variable
Data
type
Unit
Value range
Meas-
ured
value
ID
0
Version
UINT8
-
1
-
1
Reserved
UINT8
-
0
-
2...3 Qualifier L3 WORD Bit field 0b 00 00 00 00
0b qq 00 00 xx
65502
4...7
Voltage L3-N
REAL
V
0.0 ... 1000000.0
3
8...11
Current L3
REAL
A
0.0 … 100000.0
9
12...15
Apparent power L3
REAL
VA
-3.0 x 10
9
… +3.0 x 10
9
12
16...19
Active power L3
REAL
W
-3.0 x 10
9
… +3.0 x 10
9
15
20...23
Reactive power L3
REAL
var
-3.0 x 10
9
… +3.0 x 10
9
24
24...27
Power factor L3
REAL
-
0.0 ... 1.0
21
28...31
Phase angle L3
REAL
°
0.0 ... 360.0
61218
32...39
Apparent energy L3
LREAL
VAh
0.0 ... 1.8 x 10
308
61224
40...47
Total active energy L3
LREAL
Wh
-1.8 x 10
308
... +1.8 x 10
308
61225
48...55
Total reactive energy L3
LREAL
varh
-1.8 x 10
308
... +1.8 x 10
308
61226
56...59
Max. voltage UL3-N
REAL
V
0.0 ... 1000000.0
42
60...63
Max. current L3
REAL
A
0.0 ... 100000.0
48
64...67
Max. apparent power L3
REAL
VA
-3.0 x 10
9
… +3.0 x 10
9
51
68...71
Max. active power L3
REAL
W
-3.0 x 10
9
… +3.0 x 10
9
54
72...75
Max. reactive power L3
REAL
var
-3.0 x 10
9
… +3.0 x 10
9
62360
76...79
Max. power factor L3
REAL
-
0.0 ... 1.0
60
80...83
Min. voltage UL3-N
REAL
V
0.0 ... 1000000.0
72
84...87 Min. current L3 REAL A 0.0 ... 100000.0 78
88...91
Min. apparent power L3
REAL
VA
-3.0 x 10
9
… +3.0 x 10
9
81
92...95
Min. active power L3
REAL
W
-3.0 x 10
9
… +3.0 x 10
9
84
96...99
Min. reactive power Qtot L3
REAL
var
-3.0 x 10
9
… +3.0 x 10
9
62380
100...103
Min. power factor L3
REAL
-
0.0 ... 1.0
90
104...107
Reactive power Qn L3
REAL
var
-3.0 x 10
9
… +3.0 x 10
9
18
108...111
Current L3 10-12 cycles
REAL
V
0.0 ... 760.0
62330
112...115
Current L3 10-12 cycles
REAL
A
0.0 ... 100000.0
62333
116...119
Max. reactive power Qn L3
REAL
var
-3.0 x 10
9
… +3.0 x 10
9
57
120...123
Min. reactive power Qn L3
REAL
var
-3.0 x 10
9
… +3.0 x 10
9
87
124...127
Fundamental voltage L3
REAL
V
0.0 ... 440.0
62322
