Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
205
User data variants
D
User data
The following table shows the existing user data variants.
Table D- 1 Overview of the user data variants
User data
User data variant
Total power L1L2L3
254 (FE
H
) - default setting
Active power L1L2L3
253 (FD
H
)
Reactive power L1L2L3
252 (FC
H
)
Apparent power L1L2L3
251 (FB
H
)
Basic measured values L1L2L3
250 (FA
H
)
Total energy L1L2L3
249 (F9
H
)
Energy L1
248 (F8
H
)
Energy L2
247 (F7
H
)
Energy L3
246 (F6
H
)
Basic variables three-phase measurement
L1L2L3
245 (F5
H
)
Reactive power compensation
244 (F4
H
)
Quality values three-phase measurement
240 (F0
H
)
Energy measurement (periodic) overflow counter
239 (EF
H
)
EE@Industry measurement data profile E3
227 (E3
H
)
EE@Industry measurement data profile E2
226 (E2
H
)
EE@Industry measurement data profile E1
225 (E1
H
)
EE@Industry measurement data profile E0
224 (E0
H
)
Basic variables phase-specific measurement L1
159 (9F
H
)
Single-phase measurement L1 with voltage scal-
ing value
158 (9E
H
)
Basic variables phase-specific measurement L2
157 (9D
H
)
Single-phase measurement L2 with voltage scal-
ing value
156 (9C
H
)
Basic variables phase-specific measurement L3
155 (9B
H
)
Single-phase measurement L3 with voltage scal-
ing value
154 (9A
H
)
User-defined user data structure I
1 (01
H
)
User-defined user data structure II 2 (02
H
)
Information on using and dynamic switching of the user data variants can be found under
"Selecting the module versions (Page 32)".
