Limit monitoring
9.4 Measured variables for limit monitoring
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
82 Manual, 07/2018, A5E42674880-AA
Measured variables for limit monitoring
You can use measured variables from the section Measured variables (Page 163) for limit
value monitoring.
The value range of the parameter "Limit x" is -3.0E+09 ... +3.0E+09.
The table below shows you which measured variables are not available for limit monitoring.
Total active energy inflow L1L2L3
221 Total active energy outflow L1L2L3
Total reactive energy inflow L1L2L3
Total reactive energy outflow L1L2L3
Total apparent energy L1L2L3
Total active energy L1L2L3
Total reactive energy L1L2L3
Reactive energy inflow L1
Reactive energy outflow L1
Fundamental cos φ active factor L1
Reactive energy inflow L2
Reactive energy outflow L2
62215 Total active energy L2
Fundamental cos φ active factor L2
Reactive energy inflow L3
Reactive energy outflow L3
Fundamental cos φ active factor L3
Power quality analysis qualifier
