CHAPTER 2 | DEVICE PROGRAMMING UNIT USER’S MANUAL
PROGRAMMING 19
This screen allows the usage and the contact state
of the first input (#1) to be changed. Press the
TROUBLE button to change the usage setting. As
the button is pressed, the usage in the top line
changes and the label on the button sequences
between ALARM, TROUBLE, and STATUS.
Press the N/C button to change the contact state of
the input to N/C (Normally Closed). As the contact
state changes to N/C, the button toggles to N/O
(Normally Open).
• To change the settings for input 2 (#2), press NEXT.
The display will appear similar to the following:
TRI-D #2 N/O ALARM
LOOP=012 ADDRESS=41
<TROUBLE N/C>
<EXIT PROGRAM>
• Use the TROUBLE and N/C buttons to change the
settings as explained above.
• If the settings are correct, press PROGRAM to
program the TRI. If label printing is selected, up to
nine labels will be printed. If the TRI is programmed
correctly, the display will appear similar to the
following:
DUAL TRI TR/TR NC/NC
LOOP=012 ADDRESS=41
PROGRAMMED OK
<EXIT CHANGE>
Press EXIT to return to the Main Menu. Use the
CHANGE button to go back and change a setting.
• If the TRI was not programmed correctly, the display
will show;
DUAL TRI AL/AL
LOOP=012 ADDRESS=41
PROGRAMMING FAILED
<EXIT RE-DO>
To Next Page
