5.2 Reset an alarm
Before an alarm can be reset, the alarm message must be acknowledged.
To reset an alarm, the key switch must be in the horizontal position.
If the cause of an alarm isn't remedied, another alarm event will occur after resetting.
Reset alarm
1.
Turn key switch to horizontal position.
a Operation enable is set.
2.
Acknowledge the alarm message'.
3.
Press <Reset>.
a 'ALARM' is reset.
a Remote terminal is in quiescent condition if there are no other messages.
5.3 Procedure in case of trouble
Step Action
1
Press <AudiblesON/Silenced> on the Person Machine Interface
2 Read message/trouble location
on the display
3
Press <Acknowledge> on the Person Machine Interface
5 Go to the trouble location
6 Eliminate the cause of the trouble
If you cannot eliminate a 'Trouble', please contact your service provider.
'Trouble' and 'Intervention Concept' ('IC')
On consideration of 'Intervention Concept', events of the 'Trouble' category can be
assigned their own sequence. This sequence may be configured differently and
depends on the 'Occupied operation' / 'Unoccupied operation' operation mode.
An exemplary process following a 'Trouble', taking in account 'Intervention Concept', is
outlined below:
'Trouble' has occurred
● 'Unoccupied operation' operation mode
– Remote transmission for 'Troubles' is activated.
● 'Occupied operation' operation mode
– The remote transmission for 'Trouble' is activated unless 'Troubles' is
acknowledged within the delay t1.
Operation
Reset an alarm
5
18 | 22 A6V10333444_h_en_--
