Installation in desktop housing (FT2080) FHA2040
5
20 | 24
Building Technologies
A6V10462660_en
--
_b
Fire Safety
2016
04
08
Figure 17: Securing the top of the desktop housing
1 Securing cap (scope of delivery)
2 Opening for fixing screw
3 Top of the desktop housing (Touch)
4 Fixing screw with securing device
1. To close the housing, tilt the top of the housing (3) onto the housing and secure
the top to the housing using both screws (4).
2. Close the openings for the fixing screws (2) using both securing caps (1)
1
2
1
3
4
