Startup
A31003-S2010-M100-10-7619, 27/08/2008
2-14 HiPath 2000/3000/5000 - OpenStage Family, Administration Manual
inbetriebnahme.fm
Quick Start
Setup using a DHCP server on Unix/Linux
The following snippet from a DHCP configuration file (usually dhcpd.conf) shows how to set up
a configuration using a vendor class and the "vendor-encapsulated-options" option.
class "OptiIpPhone" {
option vendor-encapsulated-options
# The vendor encapsulated options consist of hexadecimal values for
the option number (for instance, 01), the length of the value (for in-
stance, 07), and the value (for instance, 53:69:65:6D:65:6E:73). The
options can be written in separate lines; the last option must be fol-
lowed by a ’;’ instead of a ’:’.
# Tag/Option #1: Vendor "Siemens"
#1 7 S i e m e n s
01:07:53:69:65:6D:65:6E:73:
# Tag/Option #2: VLAN ID
#2 4 0 0 1 0
02:04:00:00:00:0A;
match if substring (option vendor-class-identifier, 0, 11) =
"OptiIpPhone";
}
2.3.4.2 Using Option #43 "Vendor Specific"
Alternatively, option #43 can be used for setting up the VLAN ID. Two tags are required:
• Tag 001: Vendor name
• Tag 002: VLAN ID
The Vendor name tag is coded as follows (the first line indicates the ASCII values, the second
line contains the hexadecimal values):
The following example shows a VLAN ID with the decimal value "10":
Code Length Vendor name
1 7 S i e m e n s
01 07 53 69 65 6D 65 6E 73
Ta ble 2 - 1
Code Length VLAN ID
2 4 0 0 1 0
02 04 00 00 00 0A
Ta ble 2 - 2
