Description, technical data
2.8 Technical design
A5E01083943A AB
Siemens AG Operating Instructions 2.02 1FW4
33
Features Design/values
Insulation of stator winding in accordance with EN
(IEC) 60034-1
Heat class 155 (previously: F) for a maximum
winding temperature of 155°C
Type as per IEC/EN 60034-7 IM B3
Degree of protection as per IEC/EN 60034-5 IP55
Cooling as per IEC/EN 60034-6
• IC71W water-cooled
• IC416 fin-cooled with forced ventilation
Thermal motor protection acc. to IEC/EN
60034-11
KTY84 temperature sensor in the stator winding
(redundant).
Option:
6 PT100 for monitoring the winding temperature
Short shaft end as per DIN 748 with feather key
as per DIN 6885
Solid shaft
Radial eccentricity, concentricity and axial
eccentricity acc. to DIN 42955; IEC 60072-1
Tolerance class N (normal)
Vibration severity grade as per IEC/EN 60034-14 Grade A (normal)
Standard - vibration severity grade A:
rms value = 2.3 mm/s
Permissible vibration speed
1)
Optional - vibration severity grade B:
rms value = 1.5 mm/s
Bearings Deep-groove ball bearing with lubricating and re-
lubricating device
connection
• One or two terminal boxes for power cables
• Auxiliary terminal boxes (optional)
• Sensor signal:
– Directly on the sensor (water-cooled)
– Auxiliary terminal box on external fan cowl
(forced ventilation)
Installation altitude acc. to EN/IEC 60034-1 For an installation altitude > 1,000 m above sea
level
• The supplementary conditions specified in the
converter documentation must be observed
• The derating factor as per Chapter "Air
Cooling" must be observed.
Ambient Temperature during Operation -20°C to +40°C
2)
optional to +60°C
Storage temperature -20°C to +70°C
Positive direction of rotation Clockwise when looking at the drive end
1) The specified values only refer to the motor. These values can be increased at the motor due to
the overall vibration characteristics of the complete system after the drive has been mounted.
2) At temperatures below 0°C, anti-freeze is required for water-cooled motors.
