8.3 Stators and rotors for water-cooled 1FW4 motors
A5E01083943A AB
92 Siemens AG Operating Instructions 2.02 1FW4
8.3 Stators and rotors for water-cooled 1FW4 motors
Replacement parts
10.00
20.60
20.00
20.04
20.11
Figure 8-1 Stator and rotor
Table 8-1 Stator and rotor
Part Description Part Description
10.00 Stator housing (with laminated core and
winding)
20.11 Intermediate plate
20.00 Terminal box 20.60 Cable gland
20.04 Auxiliary terminal box
[ID 1132.00]
