Replacement parts
8.6 Bearing bush NDE
A5E01083943A AB
Siemens AG Operating Instructions 2.02 1FW4
95
8.6 Bearing bush NDE
Replacement parts












Figure 8-4 Bearing bush NDE
Table 8-4 Bearing bush NDE
Part Description Part Description
4.20 Outer bearing cover 4.61 Inner bearing cover
4.21 Outer bearing cover (end cover) 4.70 Insulating washer
4.30 Retaining ring 4.71 Insulating tube
4.35 Grease slinger 4.72 Insulating washer
4.41 Deep-groove ball bearing (floating bearing) 4.73 Insulating ring
4.50 Bearing housing 6.00 Bearing shield, NDE
