Replacement parts
8.8 Pulse encoder
A5E01083943A AB
Siemens AG Operating Instructions 2.02 1FW4
97
8.8 Pulse encoder
Replacement parts




Figure 8-6 Pulse encoder
Table 8-6 Pulse encoder
Part Description Part Description
55.10 Tachometer/speed sensor 55.21 Adapter flange
55.32 Shaft journal (with cone) 55.63 Torque transmission element
[ID 1137.00]
