8.4 Stators and rotors for air-cooled 1FW4 motors
A5E01083943A AB
Siemens AG Operating Instructions 2.02 1FW4
93
8.4 Stators and rotors for air-cooled 1FW4 motors
Replacement parts






Figure 8-2 Stators and rotors, air-cooled version
Table 8-2 Stator and rotor
Part Description Part Description
10.00 Stator housing (with laminated core and
winding)
20.04 Auxiliary terminal box
10.84 Cover with seal 20.10 Adapter flange
20.00 Terminal box
[ID 1133.00]
