Siemens HT-direct - Bearing Bushes

Replacement parts
8.5 Bearing bush DE
A5E01083943A AB
94 Siemens AG Operating Instructions 2.02 1FW4
8.5 Bearing bush DE
Replacement parts








Figure 8-3 Bearing bush DE
Table 8-3 Bearing bush DE
Part Description Part Description
3.10 V-ring 3.40 Deep-groove ball bearing (locating
bearing)
3.20 Outer bearing cover 3.50 Bearing housing
3.30 Retaining ring 3.61 Inner bearing cover
3.35 Grease slinger 5.00 Bearing shield, DE
