Siemens LMV52.200A2 - Connecting Cable to the E-Bus Adapter; Connecting Cable to the PC

91/301
Siemens Building Technologies Basic Documentation LMV5... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 13.08.2004
AZL COM2
8-pin RI 45
Cable
7550t02e/0704
e-bus PC adapter
25-pin SUB-D connector
RxD
1
2
3
4
5
6
7
8
TxD
GND
2
3
7
20
4
GND
U1
U2
__
__
__
__
__
When making and fitting a connecting cable between the AZL5.. and a converter, it is to
be noted that Pin 5 and Pin 7 can deliver a current of maximum 5 mA each. Adequate
insulation against other potentials must be ensured.
AZL COM1
9-pin connector
Cable
7550t01E/0502
PC COM
9-pin socket
RxD
1
2
3
4
5
6
7
8
9
TxD
GND
RxD
TxD
GND
1
2
3
4
5
6
77
88
9
Connecting cable
to the e-bus adapter
Connecting cable
to the PC
