This navigation bar can be used to switch directly to the desired operating area, and to show
and hide the sidescreen.
Navigation bar
Operator control Function
Opens the "Machinery" operating area.
Opens the tool list in the "Parameter" operating area.
Opens the "Work offset" window in the "Parameter" operating area.
Opens the "Program" operating area.
Opens the "Program manager" operating area.
Opens the "Diagnostics" operating area.
Opens the "Commissioning" operating area.
SINUMERIK Operate expansion using a sidescreen
4.2 Sidescreen with standard windows
Smart machine tool operation
20 System Manual, 12/2017, 6FC5397-7FP40-0BA0
