Operator control Function
Hides the sidescreen.
Shows the sidescreen.
4.3 Operation in the sidescreen
Open sidescreen
● Tap the arrow on the navigation bar to show the sidescreen.
The standard widgets are displayed in minimized form as the header line.
① Widget header lines
② Arrow key for showing/hiding the sidescreen
Navigating in sidescreen
● To scroll through the list of widgets, swipe vertically with 1 finger.
- OR -
● To return to the end or to the beginning of the list of widgets, swipe vertically with 3 fingers.
Open widgets
● To open a widget, tap the header line of the widget.
SINUMERIK Operate expansion using a sidescreen
4.3 Operation in the sidescreen
Smart machine tool operation
System Manual, 12/2017, 6FC5397-7FP40-0BA0 21
